Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty

Product Categories
Shijiazhuang Zhongtai Pipe Technology Development Co., Ltd
Contact Now

Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty

  • 1
  • 2
  • 3

Brand Name : ZTZG

Model Number : ERW 720

Certification : ISO9001

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 sets/year

Delivery Time : 120 days

Packaging Details : All mechanical equipment is nude packing and electrical parts are packed in wooden cases

Item : ERW76 Carbon Steel Black Square & Rectangle Tube Mill

Raw Material : Carbon steel, black steel, stainless steel, Cold roll, ow-carbon Steel,HR carbon steel,Q235,S235

Diameter : 32-76mm

Thickness : 1.5-4.0mm

Prodution Capability : 20-120m/min

Applicable Industri : Energy Supply Pipe, Building Material Shops, Energy Supply Pipe

Welding type : Solid-state high frequency welding

After Warranty Serve : Video technical support, Online support, Spare parts

Local Service Location : Egypt, Turkey, Philippines, Brazil, Peru, Saudi Arabia, Mexico, Russia

Marketing Type : New Product 2020

Warranty of core part : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Un-coiler, Hydraulic shear

Condition : New

Type : Pipe Production Line

Production Capacity : 98%

Voltage : 380-480V

Contact Now

Galvanized Pipe Welding Steel Tubing Seam Welded Pipe ERW Tube Mill

Product Introduction
A High-frequency welded pipe is also called a high-frequency straight seam welded pipe unit. It is suitable for hot rolling or cold rolling with the rigid coil (GB700-88 or GB1591-88) of plain carbon steel, such as Q195Q23516MN. Production line process: raw material (strip coil) -- feeding -- shear butt-welding (manual welding) -- storage bin -- feeding molding -- high-frequency welding -- external burr removal -- cooling water jacket -- sizing and straightening -- flying saw cutting -- blanking (manual stacking and wrapping) -- inspection -- storage

Why Us

High quality:

Optimized design, high-quality material selection, and strict heat-treatment process. The high precision, wear resistance and long service life of the roller are guaranteed

Precision assembly:

The CNC milling surface of the host pedestal, the milling base keyway, and the NC positioning bolt hole can realize the rapid positioning and installation of NC machining parts

Roll quick change:

Patented design, help you change the roll in half an hour

Smooth transmission:

The spiral bevel gear, drum-type coupling, tooth surface carburizing quenching treatment. Stable and efficient transmission, strong bearing capacity, wear resistance, low noise

Raw Material Coil Material Upto X80
Width 25~2200mm
Thickness 0.5~20.0mm
Coil ID φ450-φ520mm
Coil OD Max φ1200mm
Coil Weight 1.0~3.0Tons
Production Capacity Round Pipe 6~720mm
Square & Rectangular Pipe 6*6~600*600mm
Wall Thickness 0.5~20.0mmmm (Round Pipe)
0.5~20.0 mm(Square Pipe)
Speed Max. 100m/min
Pipe Length 6~12m
Workshop Condition Dynamic Power 380V, 3-phase,
50Hz (depends on local facilities)
Control Power 220V, single-phase, 50 Hz
Size of the whole line 65m X 6m (L*W)

Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty
Application
Mainly used in the production of round pipe, oval pipe, and rectangular pipe.

Applications of pipe: Construction, Automotive, General Mechanical Piping, Furniture, Agricultural, Chemical, Petroleum, Gas, Pipeline, Structure, Scaffold. In the field of furniture, construction, municipal facilities, and others.


Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty
Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty

Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty

ZTZG Company Introduction
Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty
Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty
Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty
Thickness 1.5-4.0mm Galvanized Pipe Mill Machine ERW 720 1 Year Warranty

FAQ

Q: Are you a manufacturer?
A: Yes, we are a manufacturer. We have 4 factories ( Machining, Assembling, Heat treatment, and Moulding ). We also have our own R&D department. Welcome to visit us.
Q: What kind of payment term do you do?
A: We do T/T.
Q: What info do you need before giving me the price and proposal?
A: Since we design individual machines based on our customer's requirements, we need your desired products' basic dimensions, including all the pipe diameter(or tube length), thickness range, usage, raw material steel grade, coil weight, and degree of automation.
Q: What should I do if I just start a new business?
A: Contact us immediately, we provide a free consultant for pre-sales service. Also, we can help you solve the raw material (steel coil) purchase, worker training, international market price, and more.
Q: How do you do QA?
A: We have a special team to do strict QA, this is one of our strengths:
(1)Every gearbox will be tested for 8 hours with oil inside to guarantee there is no leak.

(2)Every shaft will be inspected for centering jumpiness.
(3)Every roller will be checked to make sure it's in the range of tolerance critical parts will be inspected for all dimensions.
Q: Why I should choose you? what are the differences between you and other Chinese suppliers?
A: We are concentrating on pipe-making machines for more than 20 years. We have constructed many steady trading partners in Asia, Africa, the middle east, Europe, and South America throughout the years. Our innovative designed production line and every single unit of the production line are economical and practical.

Model List
Model Round pipe
mm		 Square pipe
mm		 Thickness
mm		 Working spead
m/min
ERW20 Ф8-Ф20 6x6-15x15 0.3-1.5 120
ERW32 Ф10-Ф32 10x10-25x25 0.5-2.0 120
ERW50 Ф20-Ф50 15x15-40x40 0.8-3.0 120
ERW76 Ф32-Ф76 25x25-60x60 1.2-4.0 120
ERW89 Ф42-Ф89 35x35-70x70 1.5-4.5 110
ERW114 Ф48-Ф114 40x40-90x90 1.5-4.5 65
ERW140 Ф60-Ф140 50x50-110x110 2.0-5.0 60
ERW165 Ф76-Ф165 60x60-130x130 2.0-6.0 50
ERW219 Ф89-Ф219 70x70-170x170 2.0-8.0 50
ERW273 Ф114-Ф273 90x90-210x210 3.0-10.0 45
ERW325 Ф140-Ф325 110x110-250x250 4.0-12.7 40
ERW377 Ф165-Ф377 130x130-280x280 4.0-14.0 35
ERW406 Ф219-Ф406 170x170-330x330 6.0-16.0 30
ERW508 Ф273-Ф508 210x210-400x400 6.0-18.0 25
ERW660 Ф325-Ф660 250x250-500x500 6.0-20.0 20
ERW720 Ф355-Ф720 300x300-600x600 6.0-22.0 20
